Part Number: VL-BB-1
Manufacturer: OEM
Length: 22.00 IN
Width: 16.00 IN
Thickness: 10.00 IN
Enclosure Type: Pole
Material: Aluminum
Available Finish: Mill (Standard), Powder Coat
NEMA Rating: 3R
Overall Dims (HxWxD – IN): 22 x 16 x 10
Ameresco Solar supplies and distributes a complete line of enclosures to accommodate a wide range of off-grid applications. We have a large selection of enclosures and control cabinets ranging from single battery pole, ROHN tower and wall mounted, to custom multi-battery enclosures. Our enclosure line has the flexibility to meet your storage needs.
Our VL-BB-1 Includes:
Materials
- Aluminum
Weight
- 12.5 lbs
Battery Capacity
- (1) Class : 27 Series
- (1) Class : 30 Series
- (1) Class : 31 Series
- (2) Class : U1 Series
Back Panel Dimensions (HxW – IN)
- 13.5″ x 19.0″
Features
- Back panel assembly optional
- Door has two 180° hinges
- 1/4 turn wing knob
- Pad Lockable Latch
- UV resistant
- High temperature silicon
- Heat stripping
- Bronze grounding lug
